AIE900-902-FL Fanless Edge AI Computer with Jetson AGX Xavier
Fanless Edge AI System with NVIDIA Jetson AGX Xavier SoM, 2 HDMI, 2 GbE LAN, 4 GbE PoE
Key Features:
- NVIDIA Jetson AGX Xavier with 512-core Volta GPU with 64 Tensor cores
- High AI computing performance for GPU-accelerated processing
- Ideal for intelligent edge applications, AGV, AMR and computer vision
- Supports M.2 NVMe PCIe x4 SSD slot
- Wide operating temperature from -30°C to +50°C
- JetPack supported
Introducing the AIE900-902-FL, an edge AI computing system for advanced AI-powered autonomous machine applications. This robust edge AI system adopts the NVIDIA Jetson AGX Xavier platform which has an 8-core NVDIA Carmel ARM v8.2 (64-bit) processor and 512-core NVIDIA Volta GPU with 64 Tensor cores. The high-performance AI system comes with four PoE ports and two LAN ports for 3D LiDAR and high-speed intelligent video surveillance applications. The AIE900-902-FL is a perfect platform for 3D vision-guided robots, autonomous mobile robots (AMR), intelligent video analytics, domain-focused robot assistants, intelligent roadside units, and more.
The AIE900-902-FL has a ruggedized design for harsh environments, allowing it to operate under a wide temperature range from -30°C to +50°C and vibration of up to 3 Grms. Under the ultra-compact enclosure design, the AIE900-902-FL comes with a 32GB 256-bit LPDDR4x onboard and has one M.2 Key M 2280 SSD slot with a PCIe x4 NVMe interface, one Micro SD slot and one 2.5” SSD/HDD drive bay for massive data processing and AI applications. This reliable embedded system has one full-size PCI Express Mini Card slot (USB + PCI Express signal), one M.2 Key E 2230 slot and one SIM slot for 3G/4G, GPS, Wi-Fi and Bluetooth connections. To reduce the effort and shorten the deployment process, the NVIDIA® JetPack has been pre-installed on the edge AI system for quick development. Moreover, the AIE900-902-FL is certified with CE and FCC Class A.
The AIE900-902-FL offers multiple I/O options including two lockable HDMI 2.0 ports with 4k2k supported, two 10/100/1000 Mbps Ethernet (Intel® i210-IT), four 10/100/1000 Mbps PoE (Intel® i210-IT), two USB 3.1 Gen2 ports, two USB 3.1 Gen1 ports, two USB 2.0 ports, one Micro USB port, one 8-CH DIO, two RS-232 default (or 2 x CAN by jumper settings) and four SMA-type antenna openings. There are eight LED indicators showing for power/storage/LAN/PoE active status alerts. Also included are one recovery switch and one 24 VDC power input connector.
|
CPU Board |
|
|
CPU |
|
|
GPU |
|
|
Chipset |
|
|
System Memory |
|
|
COM |
|
|
USB |
|
|
Ethernet |
|
|
Display |
|
|
Digital I/O |
|
|
Audio |
|
|
Storage |
|
|
Expansion |
|
|
Others |
|
|
Power Supply |
|
|
Watchdog Timer |
|
|
Construction |
|
|
Operating Temperature |
|
|
Relative Humidity |
|
|
Vibration |
|
|
Dimensions (W x D x H) |
|
|
Weight (net/gross) |
|
|
Certifications |
|
|
EOS Support |
|
|
Mounting |
|
