Brand: Transcend
SD/SDHC220I SD Cards
In stock
SKU:
TSxxxxSDC220I
SDC220I SD Cards combine the advantages of high performance and exceptional endurance at an affordable price.
Enquire Now
Enquire Now
Transcend's SLC Mode technology is a low-cost solution that performs similarly to SLC NAND flash. SDC220I SD Cards offer high performance and exceptional endurance at an affordable price. Because of their wide temperature range (-40°C to 85°C) and high compatibility, they are ideal for demanding industrial applications such as POS terminals, medical devices, and portable devices with an SD memory card slot.
Key Features:
- Built-in ECC (Error Correction Code) functionality
- Early Move
- Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
- Wear-Leveling
- Compliant with RoHS 2.0 standards
- Electrostatic protection (ESD IEC 61000-4-2)
- Compliant with SD specification 3.01
- High-quality MLC NAND flash and SLC mode (also called SuperMLC) for exceptional endurance and reliability
- Promised operational reliability in a wide temperature range (from -40°C to 85°C)
- Supports Transcend Scope Pro software
*Scope Pro is only available when used with the RDF5 card reader.
*TS2GSDC220I is compliant with SD specification 2.0.
Appearance |
|
| Dimensions | 24 mm x 32 mm x 2.1 mm (0.94" x 1.26" x 0.08") |
|---|---|
| Form Factor |
|
Storage |
|
| Flash Type |
|
| Capacity |
|
Operating Environment |
|
| Operating Voltage |
|
| Drop Test |
|
| Operating Temperature |
|
| Storage Temperature | -40°C (-40°F) ~ 85°C (185°F) |
| Humidity | 0% ~ 95% |
| Shock |
|
| Vibration (Operating) | 20 G (peak-to-peak), 20 Hz ~ 2,000 Hz (frequency) |
Power |
|
| Power Consumption (Max.) | 0.72 watt(s) |
Performance |
|
| Read Speed (Max.) | up to 22 MB/s |
| Write Speed (Max.) | up to 20 MB/s |
| Terabytes Written (TBW) | up to 66 TBW |
| Note |
|
